The 432 Series™ internal gear pump is the ideal solution for fuel oils, glycols, lube oils, and more liquids. It can handle up to 20 GPM (0 to 4.5 m³/h).
Features & Benefits
- Relief valve on casing or head
- Steam jacketed head
- Upright, opposite & right angle ports
- Mechanical seal
Capacity
to 20 GPM
to 4.5 m³/h
Viscosity
31 to 250,000 SSU
1 to 55,000 cSt
Pressure
to 250 PSI
to 17 Bar
Temperature
-60 to +450 °F
-50 to +230 °C
Options
Porting
Opposite (180°)
Right Angle (90°)
NPT
Drives
D Direct-Mounted Drive
B Bracket Mounted Drive
R Offset Gear Reducer Drive
V Drive | V-Belt Drive
Mounting
Motor Mount
Sealing
Mechanical Seals
Specifications
Model | Standard Port Size | Nominal Pump Rating GPM | Nominal Pump Rating m3/h | Maximum RPM | Maximum Pressure PSI | Maximum Pressure BAR |
---|---|---|---|---|---|---|
C432 | 0.25 | 0.5 | 0.11 | 1800 | 250 | 17 |
F432 | 0.5 | 1.5 | 0.34 | 1800 | 250 | 17 |
FH432 | 0.5 | 3 | 0.68 | 1800 | 250 | 17 |
G432 | 1 | 5 | 1.1 | 1200 | 100 | 7 |
H432 | 1 | 10 | 2.3 | 1200 | 100 | 7 |
HL432 | 1.5 | 20 | 4.5 | 1200 | 100 | 7 |
C thru HL sizes available UL 343 listed for fuel oil applications |
Photos
Videos
Lube Oil (Machinery Lubrication)
Machinery lubrication pumps are used in everything from small backup generators to naval ships. Lube oils, as the name implies, are the liquids used to lubricate rotating and reciprocating machinery. Lube oils may be handled at higher pressures to ensure their penetration of the equipment.
