The 4624B Series™ internal gear pump is the idea solution for inks, resin, starch, and more due to its hardened parts in key wear areas. It can handle flows from 0.75 to 182 GPM (0.17 to 41 m³/h)
Features & Benefits
- Ultra-hard tungsten carbide idler pin and tungsten carbide idler bushing minimize wear in this key area, since a constant supply of abrasive material is flowing through the pumping elements.
- Behind-the-rotor pinned-seat mechanical seal with hard silicon carbide vs. silicon carbide seal faces, featuring external flush line from pump discharge to remove solids build-up, ensuring longest possible seal life (note: no flush line on F & FH sizes).
- The grease-lubricated bracket bushing is not contacted by the pumped liquid, for long life. The pump is re-greasable, with a lip seal at the stuffing box.
Photos
Videos
Starch
Starch is derived from corn, arrowroot or potatoes. It is shear sensitive (thickens) and viscosity varies from a few centipoise to over 20,000 cP depending on the type of starch, concentration in the liquid, and temperature.
Wax
Waxes can be natural secretions of plants or animals, such as beeswax, or by-products of petroleum refining. Wax is commonly used in the paper and boxboard industries to make products such as cartons and paper packaging moisture resistant. Wax can also help prevent food products from sticking to paper packaging.
Adhesives
Adhesives are a group of substances, such as cement, glue, mucilage, and paste that are capable of holding materials together by surface attachment. Adhesives are made from many different basic materials, among them dextrin, latex, silicones, liquid rubber, resin, sodium silicate, and starch.
